Calculate Unit-Circle Coordinates and Trig Values

Start with a circle of radius one

The unit circle is centred at the origin and has equation x²+y²=1. An angle θ measured counterclockwise from the positive horizontal axis reaches the point (cosθ, sinθ). The coordinate order matters: cosine supplies x and sine supplies y. At zero degrees the point is (1, 0), at 90 degrees it is (0, 1), at 180 degrees it is (−1, 0), and at 270 degrees it is (0, −1). These axis points provide basic checks before working with oblique angles.

Calculate a point in the second quadrant

For 120 degrees, the reference angle is 60 degrees. The magnitudes of cosine and sine are 1/2 and √3/2, but the second quadrant has negative horizontal coordinate and positive vertical coordinate. Therefore the point is (−1/2,√3/2), approximately (−0.5,0.8660254). Enter 120 with Degrees selected and read the cosine and sine lines in coordinate order. Reversing them would put the point in a different location even though the same two numerical magnitudes appear.

Calculate a fourth-quadrant point

For 300 degrees, the reference angle is again 60 degrees. The fourth quadrant has positive x and negative y, giving (1/2,−√3/2). In the local calculator, cosine should be 0.5 and sine approximately −0.8660254. Tangent is their quotient, −√3≈−1.73205081. Comparing 120 and 300 degrees is useful because the two points lie opposite each other: both coordinates change sign, while the tangent values agree wherever the quotient is defined.

Build exact special-angle values

A 45–45–90 triangle with equal legs 1 has hypotenuse √2. Scaling it to hypotenuse 1 gives both legs √2/2, so the first-quadrant 45 degree point has equal coordinates. Splitting an equilateral triangle produces the 30–60–90 ratios 1:√3:2, giving the unit-circle values 1/2 and √3/2 for 30 and 60 degrees. Use these geometric relationships for exact answers. A decimal such as 0.70710678 is an approximation to √2/2, not a replacement for an exact radical when the exercise requests one.

Find signs before inserting magnitudes

The coordinate signs follow the plane: quadrant I has (+,+ ), II has (−,+ ), III has (−,−), and IV has (+,−). A reference angle is the acute angle between the terminal side and the horizontal axis. For 225 degrees it is 45 degrees, giving (−√2/2,−√2/2). For 210 degrees it is 30 degrees, giving (−√3/2,−1/2). Determining the quadrant first prevents choosing a positive square root merely because the numerical magnitude was calculated correctly.

Relate tangent to the coordinates

Where x≠0, tanθ=y/x. At 120 degrees, the quotient (√3/2)/(−1/2) equals −√3. At 90 and 270 degrees, x=0 and the tangent is undefined; the point on the circle still exists, with a perfectly valid sine and cosine. Near those angles the tangent can become very large, so rounded coordinates are unsuitable for estimating it by hand. A tiny displayed cosine should not automatically be treated as an exact zero for every nearby angle.

Convert radians and reduce full turns

The radian angle 5π/6 corresponds to 150 degrees and reaches (−√3/2,1/2). The local numeric angle field requires a numerical value, so use approximately 2.617993878 with Radians selected rather than expecting the string 5π/6 to be parsed. Adding 2π radians or 360 degrees gives the same point. Thus 510 degrees is coterminal with 150 degrees. The point records the final direction, while the original angle can retain additional revolutions that matter in a rotation problem.

Verify the circle and distinguish a general radius

For 120 degrees, squaring the exact coordinates gives 1/4+3/4=1. The squared rounded decimals should be close to one, with a small rounding difference allowed. A circle of radius r has coordinates (r cosθ, r sinθ), so a radius 4 circle at 120 degrees reaches (−2,2√3). That point is not on the unit circle because its squared distance is 16. Keep the radius and coordinate scale separate from the angle's sine and cosine ratios when adapting a unit-circle calculation to a physical circle.
